EN4080

IP Gateway

The EN4080 IP gateway combines the functionality of an Inovonics EN4000 receiver with the flexibility of an IP appliance. With a message queuing telemetry transport (MQTT) license, the IP gateway outputs messages in the MQTT protocol. With a BACnet/IP license, the IP gateway outputs messages in the BACnet/IP protocol, which is widely used for building automation and control networks.

Key Features

  • Optional Power over Ethernet (PoE) feature
  • Supports over-the-air updates
  • MQTT license compatible with all Inovonics transmitters; BACnet license compatible with Inovonics environmental, pulse counting and select security transmitters.
  • External LEDs indicate power, IP connectivity and message receipt

Frequency:

  • 902 - 928 MHz North America
  • 915 - 928 MHz Australia
  • 922 - 928 MHz New Zealand

Platform:

EchoStream ®

  • Getting started with the EN4080 IP Gateway

Compatible Products

  • ACC610

    12 VAC / 120 VAC Transformer
